Key Features
Power Your Home, Save Money
13.5 kWh Capacity
Expandable up to 40.5 kWh per unit
11.5 kW Power
Continuous on-grid and backup power
97.5% Efficiency
6 solar inputs with MPPT
10-Year Warranty
Flood and dust resistant design
How Powerwall Works
Store energy, use when needed, save money
Store Extra Energy
When your solar system generates more energy than you need, you can store the extra energy with Powerwall and save it for later. Powerwall can also recharge from the grid when utility prices are low.
Use Energy
Your stored energy is available whenever you need it—during the day, at night or when an outage occurs. A Powerwall system can power your entire home, including your heater or A/C, as well as other large appliances.
Save and Earn
Using your usage history, weather forecasts and utility price estimates, Powerwall optimizes your stored energy to power your home more efficiently, day and night. With some utilities, you can earn money by selling your energy to the grid.
Storms Happen—Outages Don't Have To
Keep your home and all appliances powered during an outage. When severe weather is forecast, Storm Watch will automatically charge Powerwall to its maximum capacity to prepare for an outage. When an outage occurs, Powerwall will help keep your solar system running or, if using grid power, will transition your home to stored energy instantly.
Maximum Efficiency, Lower Cost
Powerwall can power your entire home with one unit, making whole-home backup protection more affordable. Each unit is self-contained with an integrated solar inverter for added efficiency, resulting in fewer parts and faster installation. This helps make multi-unit systems more affordable and system expansions easier in the future.
Energy That's There When You Need It
Backup protection only works when your backup system is reliable. Powerwall is a home battery system that can be charged from solar panels or the grid and is designed to withstand extreme weather conditions and harsh environments with minimal service or maintenance. It can maintain normal operation in cold temperatures, high humidity and flooding in two feet of water. With Heat Mode, Powerwall heats itself intelligently to maintain optimal charge and discharge performance in temperatures as low as -4°F.
Powerwall History
From the beginning to 1 million installations
The Very Beginning
The first Powerwall was installed in May 2015.
Mass Production
Mass production of Powerwall started at Giga Nevada, incorporating a Tesla-designed DC-to-AC inverter.
Next Generation Powerwall
September 2023 marked the release of Powerwall 3 with integrated solar.
1 Million Powerwalls
The one millionth Powerwall was built and installed at a customer's home.
Technical Specifications
Powerwall 3 detailed specs
Energy Capacity
13.5 kWh
Additional Capacity
40.5 kWh max per unit
On-Grid Power
11.5 kW continuous
Backup Power
11.5 kW continuous
Motor Start
185 LRA
Backup Transition
Seamless
Solar-to-Grid Efficiency
97.5%
Solar Inputs
6 with Maximum Power Point Trackers
Dimensions (H x W x D)
43.5" x 24" x 7.6"
Weight
287 lbs
Operating Temperature
-4°F to 122°F
Installation
Integrated inverter and system controller
Durability
Flood and dust resistance
Certification
Meets North American safety and EMI standards
Warranty
10 years
Benefits & Features
Over 1 million Powerwalls installed globally
Power your entire home with one unit
Integrated solar inverter for added efficiency
Fewer parts and faster installation
Storm Watch automatically charges to maximum capacity
Time-Based Control optimizes for peak pricing
Seamless backup transition during outages
Heat Mode maintains performance in temperatures as low as -4°F
Withstands flooding in 2 feet of water
High humidity and harsh environment operation
System expansion available anytime
Tesla app monitoring and control
